AI-powered compression for continuous physiological sensing on edge devices.

compressionKIT helps teams reduce memory footprint, wireless bandwidth, and energy spent moving sensor data around edge systems. The current production workflow focuses on PPG compression and reconstruction, with export paths aimed at Ambiq-class embedded deployments and browser-based evaluation tools.

Key Features

  • High Compression Ratios

    Explore operating points from 2× through 16× for PPG, with clear tradeoffs between fidelity, bandwidth savings, and deployment cost.

  • Edge-Ready

    Export encoder artifacts as INT8 LiteRT and C headers for Ambiq hardware and adjacent MCU-class deployment targets.

  • Modular Architecture

    Train and evaluate from YAML configs, modular Python components, and reusable preprocessing, model, evaluation, and export stages.

  • Clinically Validated

    Measure reconstruction quality with MSE, PRD, cosine similarity, and physiology-aware evaluation paths.

Production Workflow

The current docs are organized around the path that is fully supported today: train a PPG RVQ codec, compare one of the four published operating points, and evaluate the result in export and demo surfaces.

  • 1. Understand the signal Start with the PPG pages for frame sizing, preprocessing, filters, and supported metrics.

  • 2. Choose an operating point Use the 2×, 4×, 8×, and 16× examples to match fidelity requirements to system constraints.

  • 3. Train and export Run config-driven training, then collect checkpoints, summaries, plots, LiteRT artifacts, and headers.

  • 4. Review the demo path Use the dedicated demo section when you want to review the browser and hardware evaluation experience.

That production path currently centers on a PPG RVQ codec flow with:

  • 64 Hz PPG input, trained on fixed windows and exported for embedded inference.
  • Compression operating points spanning 2×, 4×, 8×, and 16×.
  • End-to-end outputs that include checkpoints, evaluation summaries, plots, LiteRT artifacts, and deployment headers.
  • A separate demo path for browser-based and hardware-backed evaluation when needed.

The documentation below focuses on the supported PPG path first, then branches into methods, exports, and the dedicated demo material.

Supported Signal Types

Signal Status Sampling Rate Description
PPG Production 64 Hz (default) Fully documented training, evaluation, export, and demo flow
ECG In Progress 250-500 Hz Early support and legacy experimentation, with ongoing migration into the modular flow

Compression Methods

Method Type Compression Status
RVQ Autoencoder Learned 2×–16× documented Production
Wavelet + SPIHT Classical 2×–16× Experimental
Decimation Baseline 2×–16× Baseline

Quick Start

# Install
uv pip install -e .

# Train a PPG RVQ model
train-ppg-rvq --config configs/ppg_rvq_08x.yaml

# Or use the module directly
python -m compressionkit.cli.train_ppg_rvq --config configs/ppg_rvq_08x.yaml

Architecture Overview

The current reference model is a residual vector quantized autoencoder. Temporal downsampling in the encoder determines the coarse compression stage, and RVQ codebook depth determines how much discrete bitrate is allocated to each latent position. At a high level, the workflow is straightforward: the encoder compresses the incoming signal into a compact latent representation, the codebooks turn that representation into a compact discrete form, and the decoder reconstructs the waveform from that compressed representation.
flowchart LR
        A[PPG frame<br/>320 samples at 64 Hz] --> B[Encoder<br/>strided conv blocks]
    B --> C[Compressed latent]
    C --> D[RVQ codebooks]
    D --> E[Compressed code sequence]
    E --> F[Decoder]
        F --> G[Reconstructed PPG frame]
    D -. export .-> H[LiteRT model and C headers]
    G -. evaluate .-> I[Quality and efficiency metrics]

The encoder reduces the signal into a smaller representation, the Residual Vector Quantizer maps that representation through a sequence of learned codebooks, and the decoder reconstructs the waveform from the compressed representation. The total compression ratio is:

\[ \text{CR} = \frac{\text{frame\_size} \times \text{bit\_depth}}{\frac{\text{frame\_size}}{2^N} \times M \times \log_2(K)} \]

where \(K\) is the codebook size and \(N\) is the number of encoder stages.
